Size |
Vehicle size |
55.9 x 33.5 x 23.6 in (1420 x 852 x 600 mm) |
|
Package size |
41 x 33.5 x 18 in (1040 x 852 x 459 mm) |
Rider |
Payload |
Max. 220 lbs (100 kg) |
Weight |
Net weight |
Approx. 112.9 lbs (51.2 kg) |
Driving |
Height requirement |
51.2-74.8 in (130-190 cm) |
|
Recommended Age |
14+ years old |
Machine Parameters |
Speed Limit |
Approx. 23 mph (37 km/h) |
|
Reversing Speed Limit |
Approx. 1.9 mph (3 km/h) |
|
Typical Range |
Approx. 15.5 mi (25 km) |
|
Steering Ratio |
2.1:1 |
|
Ground Clearance |
Approx. 1.8 in (45 mm) |
|
Maximum slope |
15 |
|
Traversable Terrain |
Flat surface, paved road; obstacles < 0.4 in (1 cm); gaps < 1.2 in (3 cm); slopes < 15 |
|
Operating temperature |
14104F (-1040C) |
|
Storage temperature |
-4122F (-2050C) |
|
IP rating |
IPX4 |
|
Speed Mode |
ECO modemax. speed: 5 mph (8 km/h); STRADA modemax. speed: 11 mph (18 km/h); SPORT modemax. speed: 17.4 mph (28 km/h); CORSA modemax. speed: 23 mph (37 km/h). |
Battery |
Nominal Voltage |
55.5 V DC |
|
Max. Charging Voltage |
59.5 V DC |
|
Nominal Energy |
432 Wh |
|
Charging Temperature |
32–104°F (0–40°C) |
|
Battery Management System |
Over-voltage, under-voltage, short circuit, and over-heating protection. Auto-sleep and auto-wake. |
Motor |
Nominal Power |
500 W x 2 |
|
Max. Power |
2400 W x 2 |
Charger |
Input Voltage |
100-240 V ~ 50/60 Hz |
|
Output Voltage |
59.5 V DC |
|
Nominal Power |
120 W |
|
Output Current |
2A |
Front compartment battery |
Model/Quantity |
6 AA Batteries |
Brake |
Braking method |
Electronic brake + mechanical handbrake |
|
Braking distance |
20 ft (6 m) |
Tires |
Front tires |
Tire width: 3 in (80 mm); flatness ratio: 60%; hub diameter: 5 in (127 mm) |
|
Rear Tires |
Tire width: 2.7 in (68 mm); 10 2.75 in, hollow solid tire |
Light |
Headlight |
0.2 Watt white LED light bar |
|
Status indicator |
The indicator comes in three colors: blue, yellow, and red. Blue means that the vehicle is in normal condition. Yellow means that the batteries in the front compartment need to be replaced. Red means that the vehicle has a performance failure, and you need to open the app to check the cause of the failure and contact the after-sales service. |
|
Taillights |
Rull-color RGB taillight/brake light |
